cs-etm-decoder.h File Reference

#include <linux/types.h>
#include <stdio.h>

Include dependency graph for cs-etm-decoder.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	cs_etm_buffer
struct	cs_etm_packet
struct	cs_etmv4_trace_params
struct	cs_etm_trace_params
struct	cs_etm_decoder_params

Typedefs
typedef u32(*	cs_etm_mem_cb_type) (struct cs_etm_queue *, u64, size_t, u8 *)

Enumerations
enum	cs_etm_sample_type { CS_ETM_RANGE = 1 << 0, CS_ETM_TRACE_ON = 1 << 1 }
enum	{ CS_ETM_PROTO_ETMV3 = 1, CS_ETM_PROTO_ETMV4i, CS_ETM_PROTO_ETMV4d }
enum	{ CS_ETM_OPERATION_PRINT = 1, CS_ETM_OPERATION_DECODE }

Functions
int	cs_etm_decoder__process_data_block (struct cs_etm_decoder *decoder, u64 indx, const u8 *buf, size_t len, size_t *consumed)
struct cs_etm_decoder *	cs_etm_decoder__new (int num_cpu, struct cs_etm_decoder_params *d_params, struct cs_etm_trace_params t_params[])
void	cs_etm_decoder__free (struct cs_etm_decoder *decoder)
int	cs_etm_decoder__add_mem_access_cb (struct cs_etm_decoder *decoder, u64 start, u64 end, cs_etm_mem_cb_type cb_func)
int	cs_etm_decoder__get_packet (struct cs_etm_decoder *decoder, struct cs_etm_packet *packet)
int	cs_etm_decoder__reset (struct cs_etm_decoder *decoder)

Typedef Documentation

cs_etm_mem_cb_type

typedef u32(* cs_etm_mem_cb_type) (struct cs_etm_queue *, u64, size_t, u8 *)

Definition at line 42 of file cs-etm-decoder.h.

Enumeration Type Documentation

anonymous enum

anonymous enum

Enumerator
CS_ETM_PROTO_ETMV3
CS_ETM_PROTO_ETMV4i
CS_ETM_PROTO_ETMV4d

Definition at line 76 of file cs-etm-decoder.h.

anonymous enum

anonymous enum

Enumerator
CS_ETM_OPERATION_PRINT
CS_ETM_OPERATION_DECODE

Definition at line 82 of file cs-etm-decoder.h.

cs_etm_sample_type

enum cs_etm_sample_type

Enumerator
CS_ETM_RANGE
CS_ETM_TRACE_ON

Definition at line 25 of file cs-etm-decoder.h.

Function Documentation

cs_etm_decoder__add_mem_access_cb()

int cs_etm_decoder__add_mem_access_cb	(	struct cs_etm_decoder *	decoder,
		u64	start,
		u64	end,
		cs_etm_mem_cb_type	cb_func
	)

Definition at line 62 of file cs-etm-decoder.c.

Here is the call graph for this function:

cs_etm_decoder__free()

void cs_etm_decoder__free

(

struct cs_etm_decoder *

decoder

)

Definition at line 554 of file cs-etm-decoder.c.

Here is the call graph for this function:

cs_etm_decoder__get_packet()

int cs_etm_decoder__get_packet	(	struct cs_etm_decoder *	decoder,
		struct cs_etm_packet *	packet
	)

Definition at line 90 of file cs-etm-decoder.c.

cs_etm_decoder__new()

struct cs_etm_decoder* cs_etm_decoder__new	(	int	num_cpu,
		struct cs_etm_decoder_params *	d_params,
		struct cs_etm_trace_params	t_params[]
	)

Definition at line 443 of file cs-etm-decoder.c.

Here is the call graph for this function:

cs_etm_decoder__process_data_block()

int cs_etm_decoder__process_data_block	(	struct cs_etm_decoder *	decoder,
		u64	indx,
		const u8 *	buf,
		size_t	len,
		size_t *	consumed
	)

Definition at line 506 of file cs-etm-decoder.c.

cs_etm_decoder__reset()

int cs_etm_decoder__reset

(

struct cs_etm_decoder *

decoder

)

Definition at line 76 of file cs-etm-decoder.c.
